C48系列

概述：
红狮C48系列计数器/定时器面板仪表分为标准和批量两种型号。标准型带有单或双预设值，而批量型则具有一个带双预设值的主过程计数器/定时器和一个带单预设值的辅助计数器。后者可作为批量或总量计数器。

显示：
C48系列内嵌一块两行6位LCD数显，提供正显反射或背光负显透射（上红下绿）两种显示模式。

输入：
C48系列提供一路可选输入，可以接受各种不同的传感器的信号。该产品还具有可编程用户输入和前面板功能键。用户可以通过一根接插跳线将输入配置为无源（低位激活）或有源（高位激活）输入。用户输入和前面板功能键可以配置用来提供各种功能。

性能：
C48系列的所有型号都可以提供NPN无源电流或PNP有源电流型固态输出（视型号而异）、集电极开路晶体管输出。所有的继电器输出板都可现场更换。

Products:

Part #	Function	Size	Display	Power	NPN O.C. Output	Relay Output(s)	Comms
C48CS003	Single Preset Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	Yes	Yes	No
C48CS013	Single Preset Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	DC	Yes	Yes	No
C48CS103	Single Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	Yes	No
C48CS113	Single Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	Yes	Yes	No
C48CD115	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	Yes	No	Yes
C48CD117	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	No	Yes	Yes
C48CP005	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	Yes	No	Yes
C48CP015	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	DC	Yes	No	Yes
C48CD002	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	No	Yes	No
C48CP100	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	No	No
C48CD005	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	Yes	No	Yes
C48CP105	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	No	Yes
C48CD007	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	No	Yes	Yes
C48CP110	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	Yes	No	No
C48CD012	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	DC	No	Yes	No
C48CP115	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	Yes	No	Yes
C48CD015	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	DC	Yes	No	Yes
C48CD017	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	DC	No	Yes	Yes
C48CD100	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	No	No
C48CD102	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	No	Yes	No
C48CD105	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	No	Yes
C48CD107	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	No	Yes	Yes
C48CD110	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	Yes	No	No
C48CD112	Dual Preset Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	No	Yes	No
C48CB103	Batch Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	Yes	No
C48CB105	Batch Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	No	Yes
C48CB108	Batch Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	Yes	Yes
C48CB110	Batch Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	Yes	No	No
C48CB003	Batch Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	Yes	Yes	No
C48CB005	Batch Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	Yes	No	Yes
C48CB008	Batch Counter	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	Yes	Yes	Yes
C48CB100	Batch Counter	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	No	No
C48TS003	Single Preset Timer	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	Yes	Yes	No
C48TS013	Single Preset Timer	1/16 DIN	2 Line, 6 Digit Reflective LCD	DC	Yes	Yes	No
C48TS103	Single Preset Timer	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	Yes	No
C48TS113	Single Preset Timer	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	Yes	Yes	No
C48TD102	Dual Preset Timer	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	No	Yes	No
C48TD105	Dual Preset Timer	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	Yes	No	Yes
C48TD107	Dual Preset Timer	1/16 DIN	2 Line, 6 Digit Backlight LCD	AC	No	Yes	Yes
C48TD112	Dual Preset Timer	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	No	Yes	No
C48TD117	Dual Preset Timer	1/16 DIN	2 Line, 6 Digit Backlight LCD	DC	No	Yes	Yes
C48TD002	Dual Preset Timer	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	No	Yes	No
C48TD005	Dual Preset Timer	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	Yes	No	Yes
C48TD007	Dual Preset Timer	1/16 DIN	2 Line, 6 Digit Reflective LCD	AC	No	Yes	Yes
C48TD012	Dual Preset Timer	1/16 DIN	2 Line, 6 Digit Reflective LCD	DC	No	Yes	No
