Anything in. Anything out. And that’s just the beginning.
Overview
Red Lion’s FlexEdge® Intelligent Edge Automation Platform brings industrial data together as never before to transform edge computing. FlexEdge provides a scalable solution to integrate complex multi-vendor environments into digital transformation strategies, while providing a futureproof solution for changing application needs.
One Platform. Limitless Potential.
Avoid costly and complex rip-and-replace scenarios by leveraging the FlexEdge sled architecture, designed to enable organizations to leverage new communications technologies as they become available.
Backward Compatible. Forward Thinking.
Built with advanced networking capabilities at the core, providing powerful and secure networking to any industrial application is easy. Powered by Crimson® 3.2, FlexEdge enables connectivity to virtually anything in your system with point-and-click simplicity. And the new equipment working with the existing infrastructure means capital budgets are kept in check.
Plug and play. And plug. And play.
The FlexEdge form factor adapts as applications needs change; effortlessly scale by adding up to ten hot-swappable I/O or PID modules. On-device wiring diagrams and removable wire clamp screw terminal blocks ease installation, while the at-a-glance module status indicator and individual channel LEDs improve troubleshooting and system testing.
Software Defined Gateway. Field Upgradable.
Select the right FlexEdge software functionality for the application. Select from Networking Gateway, Protocol Gateway, Advanced IIoT Gateway, or an Automation Controller with IEC 61131 capabilities. If the application changes, simply upgrade the gateway to meet the applications requirements, it’s that easy. Reduce or eliminate costly equipment changes as simply as pushing new software.
Rugged Outside. Reliable Inside.
Rugged construction, a wide operating temperature range, industrial certifications and Red Lion’s Crimson® software provide a dependable solution for control, networking and data visualization in even the harshest environments.
Note: Add on I/O modules are only available for DA70A units with Group 2 and higher.
Design your ideal FlexEdge solution >
DA50A 1-Sled Modular Gateway
The DA50A features one communication sled, and on-board I/O. A variety of serial and Ethernet ports enable easy integration to any application.
DA70A 3-Sled Modular Gateway with Scalable I/O
The modular design of the DA70A allows for up to three communications sleds to be added as requirements change or new communication standards emerge. Rugged, field-installable PID control and I/O modules ensure a solution that adapts to meet almost any industrial application need.
| DA50A | DA70A (1x232, 2x485 Serial Ports) | DA70A (2x232, 1x485 Serial Ports) | |
| Networking Gateway | DA50A0BNN0000010 | DA70A0GNNNNNN010 | DA70A0FNNNNNN010 |
| Protocol Gateway | DA50A0BNN0000020 | DA70A0GNNNNNN020 | DA70A0FNNNNNN020 |
| Advanced IIoT Gateway | DA50A0BNN0000030 | DA70A0GNNNNNN030 | DA70A0FNNNNNN030 |
| Advanced IIoT Gateway (HDMI® enabled) |
DA50A1BNN0000030 | DA70A1GNNNNNN030 | DA70A1FNNNNNN030 |
| Automation Controller | DA50A0BNN0000040 | DA70A0GNNNNNN040 | DA70A0FNNNNNN040 |
| Automation Controller (HDMI® enabled) |
DA50A1BNN0000040 | DA70A1GNNNNNN040 | DA70A1FNNNNNN040 |
Communications Sleds
Future-proof your installation and avoid costly and complex rip-and-replace scenarios by enabling your organization to leverage new communications technologies as they become available.
| Model Number | Description |
| DAS00CL9C4SAM000 | 4G LTE (Cat. 4) Cellular Sled for North America |
| DAS00CL9C4SVZ000 | 4G LTE (Cat. 4) Cellular Sled for North America (Verizon) |
| DAS00CL9C4SEU000 | 4G LTE (Cat. 4) Cellular Sled for EU, SE Asia, and Asia Pacific |
| DAS00CL9C1SAZ000 | 4G LTE (Cat. 1) Cellular Sled for Australia |
| DAS00WF10N0AM000 | 802.11 b/g/n Wi-Fi Sled |
| DAS00PN1EE200000 | Dual Ethernet Port Sled |
| DAS00PN8CA6IS000 | CAN Protocol Sled |
| DAS00PN8J16IS000 | J1939 Protocol Sled |
| DAS00PN2221IS000 | Dual Isolated RS-232 Ports Sled |
| DAS00PN2442IS000 | Dual Isolated RS-485 Ports Sled |
| DAS00PN2245IS000 | Mixed Isolated RS-232/RS-485 Ports Sled |
| DAS00PN40U400000 | 1 Port USB 2.0 Host Sled |
I/O and PID Control Modules
The modular design of the DA70A allows for up to three communications sleds to be added as requirements change or new communication standards emerge. Rugged, field-installable PID control and I/O modules ensure a solution that adapts to meet almost any industrial application need.
| Model Number | Description |
| DAM00I0DI0000000 | Eight (8) Digital Inputs, Eight (8) SSR Outputs |
| DAM00I0DI0R00000 | Eight (8) Digital Inputs, Eight (8) Relay Outputs |
| DAM00I0UIN6I0000 | Six (6) Universal Inputs |
| DAM00I00UT8I0000 | Eight (8) Analog Outputs |
| DAM00I08R0000000 | Eight (8) Relay Outputs |
| DAM00I0IN2DA0000 | I/O Mix Module with 2UI |
| DAM00I0IN4DA0000 | I/O Mix Module with 4UI |
| DAM00PDP1RA00000 | Single PID, Relay and Analog Outputs |
| DAM00PDP1SA00000 | Single PID, SSR and Analog Outputs |
| DAM00PDP2R000000 | Dual PID, Relay Outputs |
| DAM00PDP2S000000 | Dual PID, SSR Outputs |
| DAM00PDP2SM00000 | Dual PID, SSR and Heater Current Monitor |
